Vertex Features properties

Adjust the Vertex Features brush properties and use brush actions to edit a trunk or a branch.

To access the Vertex Features properties, select a node in Freehand mode, and in the Vertex section, select Features.

The Vertex Colors properties in the Properties bar

Shape

Adjust the brush shape properties.

Property Description
Size Control the brush diameter/area of effect.
Falloff Control the falloff area of the brush. Higher values result in a more pronounced decrease in intensity from the center to the edge.
Strength Control the strength of the brush. Higher values result in more vertices painted at once.

Brush

Select a brush type to paint.

Note
  • To enable the brush, in the Tree window, hold your keyboard space bar.
  • To paint, hold left click (unless otherwise noted in the brush description below) and move across the surface.
Property Description
Adjust (+/-) Increase or decrease vertex detail in the brush area.
  • Left click: Add more vertices.
  • Right click: Remove vertices.
Airbrush Bring the brush area to the specified value.
Smooth Average out everything in the brush area. Soften and blend contours.
Erase Erase vertex detail in the brush area.

Actions

Select actions that apply to the whole selected node.

Property Description
Fill Apply the specified value to the whole surface of the selected node.
Clear Remove all your vertex feature changes.
